Product Specification
Physical
· 2 position desk stand
· 24.9 cm W x 14.7 cm D x 11.5cm D (9.8''W x 5.8''D x 4.5''H)
· 850 g (30.0 oz.)
Power
· Compatible with IEEE 802.3af inline power device
· Optional Power Over Ethernet (POE) injector available for networks that do not supply power
· Universal PSU supplied as standard
Handset / Headset
· Modular RJ9 headset connector, compatible with business headsets
· Hearing aid compatible handset
· Quality speakerphone
Display
· 3.5'' x 2.25'', 8 line, backlit display
Feature Keys
· 4 call appearance lines
· 4 navigational keys
· 6 customisable softkeys; programmable up to 20 functions.
· 8 predefined hard keys for most common call handling functions including Call Transfer, Conference, Intercom, Hold, Redial, Mute
Networking
· Dual 10/100 Mbps switched Ethernet ports
· Manual or Dynamic Host Configuration Protocol (DHCP) IP address set-up
· Time and date synchronisation using SNTP
· Built-in HTTP server for web administration and maintenance
· Server provisioned user configuration files
Protocols / Codecs IETF SIP (RFC3261) IETF MGCP (RFC3435) G.711 μ-law / A-law G.729
Feature Highlights* Up to 9 call appearance lines, Personal directory, Call forward, Call transfer, Call waiting, Caller and calling line information, Callers log, Conference, Hold, Redial list, Live dial pad or pre-dial support, MWI, BLF support, auto-answer, directed call pickup, XML support.
* Feature availability dependent on IP telephony system
